MINIB Floor convector PM90e

MINIB PM90e - Mini convector with cooling 90mm Universal solution for year-round climate comfort - heating and cooling. With fan Heating Cooling Dry rooms For heat pumps Technical parameters Heat output Q [W] at different fan lengths and speeds. Conditions: water 75/65°C, air 20°C. Heating 900 1000 1250 1500 1750 2000 2250 2500 2750 3000 Q [W] (0) - no 65 72 90 108 126 144 162 180 198 216 Q [W] (1) - low 297 330 413 495 578 660 743 825 908 990 Q [W] (2) - medium 421 468 585 702 819 936 1053 1170 1287 1404 Q [W] (3) - high 540 600 750 900 1050 1200 1350 1500 1650 1800 Cooling 900 1000 1250 1500 1750 2000 2250 2500 2750 3000 Q [W] (0) 26 29 36 43 50 58 65 72 79 86 Q [W] (1) 119 132 165 198 231 264 297 330 363 396 Q [W] (2) 168 187 234 281 328 374 421 468 515 562 Q [W] (3) 216 240 300 360 420 480 540 600 660 720 The technical parameters are set according to the relevant standards. Actual values ​​may vary depending on placement, grid type and connection. Specifications Width 175 mm Height 90 mm Length 900 - 3000 mm Power 600 W/m Features: Compact with cooling Narrow channel Grids and accessories Aluminum blind Wooden blind Stainless blind Aluminum silver Aluminum bronze Stainless steel Standard frame Documentation 📄 Download technical sheet (PDF) Manufacturer: MINIB - www.minib.cz
